High-end 0.1-6Nm Manual Adjustable Hex Socket Preset Torque Screwdriver
Features
◇ The torque value can be preset and has an audible alarm prompt. When the tightening torque of the fastener reaches the preset torque value, it can automatically emit a signal “kada”, accompanied by obvious hand vibration, indicating that the work is completed. After the force is removed, each related part is automatically reset.
◇ Automatic switching in the reverse direction, easy to use in both directions.
◇ Using the scale circle plus the scale wheel, the scale line reading is clear and accurate
◇ Aluminum alloy material forging, durable, long life.
◇ This torque screwdriver implements the relevant regulations of GB/T 1572-2008.
◇ There are two Phillips screwdriver heads inside, which allow the customer to replace the screwdriver head according to the items they want to measure.
Product specification
|
Model |
NGQ-0.6 |
NGQ-1.2 |
NGQ-3 |
NGQ-6 |
|
Brand |
NEWJIELI |
|||
|
Customized support |
OEM |
|||
|
Range(N.m) |
0.1-0.6 |
0.2-1.2 |
0.5-3 |
1-6 |
|
Unit |
N.m |
|||
|
Division Value(N.m) |
0.01 |
0.02 |
0.05 |
0.1 |
|
Precision |
±5% |
|||
|
Screw Head Type |
HEX |
|||
|
Length(mm) |
164 |
187 |
||
|
Joint size |
6.35 Hexagon |
|||
|
Handle outer diameter |
∅35mm |
∅41mm |
||
|
Gross weight(kg) |
0.3 |
0.4 |
||
| Place of origin | Zhejiang, China | |||
Product structure
Note:
● This product is only suitable for tightening and detection within the calibration range value.
● Do not strongly impact use are absolutely
● Do not allowed to act as other tools.
● Do not continue the force after the screwdriver "clicks" the alarm.
● The measured value of this product has been corrected, it is not allowed to is assemble privately, so as not to cause errors in the measurement accuracy.
● After the is finished,the torsion value should be adjusted to zero position to maintain the lifting accuracy and prolong the service life.
● This product do not contact with acid.alkali,and its corrosive gas.
Packing list
|
No. |
Name |
Qty |
|
1 |
Packing boxes |
1 |
|
2 |
Airframe |
1 |
|
3 |
Batch |
2 |
|
4 |
Product specification |
1 |
|
5 |
Product Certificate |
1 |
|
6 |
Desiccant |
1 |
