Precision Lever Type Displacement Sensor for Accurate Measurement
Features
● Compact size, high precision, and long mechanical lifespan.
● Tungsten carbide probe for direct contact with workpiece surface.
● Flame-retardant braided mesh sleeve for enhanced safety.
● Easy installation with strong environmental adaptability, making it a viable alternative to imported sensors.
Product Specification
| Model | NGW-0.7 | ||
| Measurement Range | 0.7mm(±0.35) | Standard Probe | Minimum Contact: 1.5mm |
| Coil Type | Half Bridge | Excitation Current | 1 |
| Excitation Frequency(KHZ) | 10 | Fatigue Testing | 15 Million |
| Drive Method | Rebound Type | Operating Temperature | ’-10°C to 65°C |
| Repeatability Accuracy (µm) | ≤0.15 | Standard Protective Sleeve Temperature Drift Coefficient |
Fluoroelastomer |
| Repeatability Accuracy(μm) | ≤ 3(0.3%) | Standard Protective Sleeve Temperature Drift Coefficient(%F.S./℃) |
≤0.01 |
| Linear Error Measurement Force (Newton +30%) |
1N | Resolution(μm) | 0.1 |
| Protection Level - | IP65 | Cable Length(Customizable) | 2M |
| Sensor Probe | Tungsten Carbide | Wire Exit Method | Straight Exit |
| Cable Outer Flame-Retardant Braided Mesh Protection |
√ | Standard Connector | Longbow |
