Precision Digital Torque Tester for Accurate Measurements
product detail
Features
- High precision, high resolution, fast sampling speed, full screen display.
- Using a high-precision torsion sensor with torsional direction indication.
- The setting of upper and lower limits, red-green indicator lights and buzzers for acoustic warning.
- Three units can be converted into each other, available options are (N·m, kgf·cm, lb·in).
- Real-time, peak value, automatic peak three modes can be switched at will.
- USB interface is used to communicate with PC. Synchronous testing function can connect to computer for testing. Computer can synchronously display the test force curve diagram and detailed records of the test force during the test process, which can be saved, printed and analyzed.
- Peak holding, automatic elimination function, free time setting.
- Large storage capacity, up to 99 groups of test data can be stored.
- Automatic shutdown without operation, time can be set freely.
Product specifications
|
Type
Index |
With printer |
NST-1 |
NST-2 |
NST-3 |
NST-5 |
NST-10 |
NST-20 |
|
No printer |
NST-1P |
NST-2P |
NST-3P |
NST-5P |
NST-10P |
NST-20P |
|
|
Measuring range / Division value |
N·m |
1.0000 0.0001 |
2.0000 0.0001 |
3.0000 0.0001 |
5.0000 0.0001 |
10.000 0.001 |
20.000 0.001 |
|
Kgf·cm |
10.210 0.001 |
20.421 0.001 |
30.631 0.001 |
51.052 0.001 |
102.10 0.01 |
204.21 0.01 |
|
|
Ib·in |
8.862 0.001 |
17.724 0.001 |
26.586 0.001 |
44.311 0.001 |
88.62 0.01 |
177.24 0.01 |
|
|
Precision |
±1%(10%~100% of full scale) |
||||||
|
Power |
8.4V 1.2VX7 Ni-MH Battery group |
||||||
|
Charging Time |
4～6 Hours |
||||||
|
Continuous using time of battery |
About 10 Hours |
||||||
|
Battery life |
≥300 times |
||||||
|
Size |
With printer：230mm×95mm×180mm No printer：230mm×70mm×125mm |
||||||
|
Net Weight |
With printer：4KG No printer：2KG |
||||||
|
Power adapter |
Input：AC 110-220V 50HZ Output：DC 12V 500mA |
||||||
|
Type
Index |
With printer |
NST-50 |
NST-100 |
NST-200 |
NST-300 |
NST-500 |
|
No printer |
NST-50P |
NST-100P |
NST-200P |
NST-300P |
NST-500P |
|
|
Measuring range / Division value |
N·m |
50.000 0.001 |
100.00 0.01 |
200.00 0.01 |
300.00 0.01 |
500.00 0.01 |
|
Kgf·cm |
510.52 0.01 |
1021.0 0.1 |
2042.0 0.1 |
3063.1 0.1 |
5105.2 0.1 |
|
|
Ib·in |
443.11 0.01 |
886.2 0.1 |
1772.4 0.1 |
2658.6 0.1 |
4431.1 0.1 |
|
|
Precision |
±1%(10%~100% of full scale) |
|||||
|
Power |
8.4V 1.2VX7 Ni-MH Battery group |
|||||
|
Charging Time |
4～6 Hours |
|||||
|
Continuous using time of battery |
About 10 Hours |
|||||
|
Battery life |
≥300 times |
|||||
|
Size(mm) |
With printer：Host display part 230×130×80 Measuring device part Φ59×55 No printer：Host display part 230×200×105 Measuring device part Φ59×55 |
With printer：Host display part 230×130×80 Measuring device part Φ68×75 No printer：Host display part 230×200×105 Measuring device part Φ68×75 |
||||
|
Net Weight |
With printer：4KG No printer：3KG |
|||||
|
Power adapter |
Input：AC 220V 50HZ Output：DC 12V 500mA |
|||||
|
Type
Index |
With printer |
NST-1000 |
NST-2000 |
NST-3000 |
NST-5000 |
|
No printer |
NST-1000P |
NST-2000P |
NST-3000P |
NST-5000P |
|
|
Measuring range / Division value |
N·m |
1000.0 0.1 |
2000.0 0.1 |
3000.0 0.1 |
5000.0 0.1 |
|
Kgf·cm |
10210 1 |
20420 1 |
30630 1 |
51051 1 |
|
|
Ib·in |
88622 1 |
17724 1 |
26586 1 |
44311 1 |
|
|
Precision |
±1%(10%~100% of full scale) |
||||
|
Power |
8.4V 1.2VX7 Ni-MH Battery group |
||||
|
Charging Time |
4～6 Hours |
||||
|
Continuous using time of battery |
About 10 Hours |
||||
|
Battery life |
≥300 times |
||||
|
Size |
With printer：Host display part 230mm×95mm×180mm
No printer：Host display part 230mm×70mm×125mm
|
||||
|
Net Weight |
With printer：36KG No printer：34KG |
||||
|
Power adapter |
Input：AC 220V 50HZ Output：DC 12V 500mA |
||||
Function and name of each component
- LCD Communication interface
- Indicating lamp Torque sensor
- Function keys Printer
- Power sockect
- Communication interface
- Torque sensor
- Printer
