NEWJIELI NLT-DK 0.1-8 Kgf·cm High Accuracy Preset Torque Screwdriver

The NLT-DK series preset torque wrench is a precision tool specifically designed for the purpose of tightening and loosening bolts to a predetermined torque value. Its application is highly suitable across various industries, including those that deal with precision instruments, intricate machinery manufacturing, as well as the automotive and motorcycle production sectors. This series of torque wrenches ensures that fasteners are tightened to the exact specifications required, preventing over-tightening or under-tightening which could lead to equipment malfunction or failure.

product details

Features

● Can be set to the required torque value, when the actual torque reaches the set value, it will automatically alarm, prompting that the operation is completed.
● The main scale has a vernier scale, which can intuitively read the torque value.
●Made of high quality steel, after heat treatment, durable.
● Meet GB/T15729-2008 requirements.

Product specifications

Model	NLT-DK0.6	NLT-DK1.2	NLT-DK3	NLT-DK6	NLT-DK8
Range（N.m)	0.1-0.6	0.2-1.2	0.5-3	1-6	2-8
Division（N.m)	0.02	0.04	0.1	0.2	0.2
Dimension (MM)	150		160		170
Accuracy	±5%
Handle outer diameter	Φ27mm		Φ30mm		Φ34mm
Joint size	6.35 Hexagon
Gross Weight (Kg)	0.16		0.22		0.34
Brand	NEWJIELI
Place of Origin	Zhejiang, China
Grade	Industrial
Warranty	1
